• Portable Commercial Wall Mount Humidifier
• Practical Room Size: 1000 square feet per unit (8,000 cubic feet)
• Generate and maintain any level of required humidity from 1% to 99% without wetting
• Can be used as a handheld / portable fogging disinfection system by choosing handle / hose option below
• Accurate, consistent humidity throughout the room ±1%
• Consistent, super-fast evaporating 4.2 micron droplet size
• Elimination of mold, bacteria & dust with disinfectant solution
• No drains, no pumps or fans required
• No wet-spots – Guaranteed
• No white mineral spots – not ultrasonic
• No drains, pumps or fans needed
• Maintenance free-no nozzle replacements
• Best for: Electronics Manufacturing – Laboratories – Printing Rooms -Textile Manufacturing – Large Walk In Cigar Humidors – Tobacco Storage – Wineries – Mold Remediation – Dog Daycare – Veterinary Facilities – Cannabis Grower and Greenhouses

Features:

• Consistent 4.2 Micron Droplet (Smallest, most consistent droplet size available today)
• Modular Design–multiple units can be used for larger applications, more zones, etc (call for details 800-701-2513)
• Can provide Direct to Space or HVAC Humidification
• 24/7 Automated Operation
• Powerful 12.45 lbs of Moisture Per Hour, Per Unit!
• Maintenance-free–no nozzles to replace
• Uses common compressed air – 2-4 CFM at 100 PSI
• Disinfect/sanitize a room with any water-dissolving disinfectant, hydrogen peroxide, etc.
• Advanced Smart Fog AirNet Technology (for Equal droplet spacing)
• Cold Fog (No condensation)
• Works at all temperatures (30°F-150°F)
• Durable non-clogging system.
• Reliable Industrial PLC Humidity Control – better, more accurate than cheap humidistats
• Optional ZeroTDS Water Filtration System
• 1 Year Warranty

• Type: Mobile Spot or Room Humidifier / Fogging Room Disinfection System
• Droplet Size: 4.2 Microns
• Power: 110VAC 60hz
• Watts: 0.4 kW/hr
• Water: 1.5 Gallons Per Hour, 1-10 psi
• Dimensions: 18″ W x 14.5″D x 21″ T
• Weight: 44 lbs
• Compressed Air Requirements: 2-4 CFM at 100 PSI
• Hand-Fill: No
• Water Source: Water Line Hookup, Tap Water OK
• Power cord length: 5 ft
• Lead time: 2-3 business days

This System Includes:

• 1 ES100-1WM – Direct Space Wall Mount Humidifier
• 1 AF1000 – Air Filter Set 1000 L/min [35 cfm]
• 1 PFK – Pipe and Fittings Kit

Installation / Operation Requirements (Not Included)

• Air Compressor–Screw or Piston Compressor or Source of Compressed Air with airflow at 3 CFM (72 LPM ) @ 110 psi (7 Bar)
• 120-240VAC electrical supply
• Water supply, at minimum pressure of 10 psi (3 Bar) with Max flow rate: 2 GPH (6 LPH

Optional Items:

• Intelligent Control System with 1 PB1 – Control Center ( 1 Zone ), 1 CPLC1 – Intelligent Controller ( 1 Zone ), 1 S2V – Relative Humidity Sensor V Series (+/- 2%)
• ZeroTDS Water Filtration System
• Disinfectant Injection Kit–only needed for concentrated disinfectants; unit pulls pre-mixed solution direct from container.
